as 引用模块（ android stdio modules ）-白红宇

as 模块使用 android stdio modules

1.在gradle 中添加变量

# Project-wide Gradle settings.# IDE (e.g. Android Studio) users:# Gradle settings configured through the IDE *will override*# any settings specified in this file.# For more details on how to configure your build environment visit# http://www.gradle.org/docs/current/userguide/build_environment.html# Specifies the JVM arguments used for the daemon process.# The setting is particularly useful for tweaking memory settings.org.gradle.jvmargs=-Xmx1536m# When configured, Gradle will run in incubating parallel mode.# This option should only be used with decoupled projects. More details, visit# http://www.gradle.org/docs/current/userguide/multi_project_builds.html#sec:decoupled_projects# org.gradle.parallel=true# org.gradle.parallel=trueCOMPILE_SDK_VERSION=24BUILD_TOOLS_VERSION=24.0.3JUNIT_VERSION=4.12SUPPORT_VERSION=24.2.1#verticalrefreshlayoutLIB_MINI_SDK_VERSION=16LIB_TARGET_SDK_VERSION=24#sampleSAMPLE_MIN_SDK_VERSION=16SAMPLE_TARGET_SDK_VERSION=23

2.修改app 中引用

apply plugin: 'com.android.application'android {    compileSdkVersion Integer.parseInt(COMPILE_SDK_VERSION)    buildToolsVersion BUILD_TOOLS_VERSION    defaultConfig {        applicationId "cn.baoyou.curiousby.com.newrproject"        minSdkVersion SAMPLE_MIN_SDK_VERSION        targetSdkVersion SAMPLE_TARGET_SDK_VERSION        versionCode 1        versionName "1.0"        testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner"    }    buildTypes {        release {            minifyEnabled false            proguardFiles getDefaultProguardFile('proguard-android.txt'), 'proguard-rules.pro'        }    }}dependencies {    compile fileTree(dir: 'libs', include: ['*.jar'])    androidTestCompile('com.android.support.test.espresso:espresso-core:2.2.2', {        exclude group: 'com.android.support', module: 'support-annotations'    })    compile "com.android.support:appcompat-v7:$SUPPORT_VERSION"    compile "com.android.support:recyclerview-v7:$SUPPORT_VERSION"    compile "com.android.support:design:$SUPPORT_VERSION"    compile 'com.tomergoldst.android:tooltips:1.0.6'    compile 'q.rorbin:badgeview:1.0.5'    compile 'com.muddzdev:styleabletoast:1.0.5'    compile 'com.wang.avi:library:2.1.3'    testCompile "junit:junit:$JUNIT_VERSION"    compile project(":verticalrefreshlayout")    compile project(":xrecyclerview")}

3. 选择 file -> new -> import module

3. 下载 github 上一些开源 module 引入

本文是引用 github xrecyclerview 链接https://github.com/curoiusby/XRecyclerView

4. 修改开源 module 中配置

5. snyc now

6.test

补充内容：

as 快捷键

注释代码(//)	Cmd + /	Ctrl + /
注释代码(/**/)	Cmd + Option + /	Ctrl + Shift + /
格式化代码	Cmd + Option + L	Ctrl + Alt + L
清除无效包引用	Option + Control + O	Alt + Ctrl + O
查找	Cmd + F	Ctrl + F
查找+替换	Cmd + R	Ctrl + R
上下移动代码	Option + Shift + Up/Down	Alt + Shift + Up/Down
删除行	Cmd + Delete	Ctrl + Y
扩大缩小选中范围	Option + Up/Down	Ctrl + W/Ctrl + Shift + W
快捷生成结构体	Cmd + Option + T	Ctrl + Alt + T
快捷覆写方法	Cmd + O	Ctrl + O
快捷定位到行首/尾	Cmd + Left/Right	Ctrl + Left/Right
折叠展开代码块	Cmd + Plus,Minus	Ctrl + Plus/Minus
折叠展开全部代码块	Cmd + Shift + Plus,Minus	Ctrl + Shift + Plus,Minus
文件方法结构	Cmd + F12	Ctrl + F12
查找调用的位置	Ctrl + Option + H	Ctrl + Alt + H
大小写转换	Cmd + Shift + U	Ctrl + Shift + U
